| 1 | Max web width | 370mm |
| 2 | Range of foil width | 20~330mm |
| 3 | Max inkjet speed | 50m/min ( Depending on the substrate material) |
| 4 | Max foil stamping speed | 50m/min （Depending on the substrate material） |
| 5 | Unwind roll diameter | Ф500mm |
| 6 | Rewind roll diameter | Ф500mm |
| 7 | Applicable material | Roll-fed material |
| 8 | Web guide | Standard |
| 9 | Foil stamping method | Cold stamping (Optional for rotary hot stamping) |
| 10 | Print thickness | 10~100 µm(Depending on the substrate material) |
| 11 | Inkjet unit | 1 set |
| 12 | Stamping unit | 1 set |
| 13 | Cooling mode | Water-cooling |
| 14 | LED UV( Precuring) | 1 set |
| 15 | UV Mercury lamp UV | 1 set |
| 16 | Static observer | 1 set |
| 17 | Web cean device | 1 set |
| 18 | Corona device | 1 set |
| 19 | Rewinding shaft | 1 set |
| 20 | Air requirement | 0.4-0.6Mpa |
| 21 | Voltage | 3PH+N+PE 380V |
| 22 | Rated current | 60A |
| 23 | Dimension(L*W*H) | 2800mm*1850mm*2000mm |
| 24 | Tooling | 1 set |
