| Standard configurations | |
| Full servo auto. Lifting blade | 3 blades |
| Auto. web guide | 1set |
| CCDQR code positioner and auto job change | 1 set（Option） |
| Tooling | 1set |
| Model | 350 |
| Format of cutting artwork | AI/DXF/PDF |
| Max web width | 350mm |
| Max repeat length | 980mm |
| Min gap/max gap of 3 blades | 65mm/260mm |
| Max unwind/rewind roll diameter | Ф500mm |
| Air requirement | 0.6Mpa |
| Voltage | 3PH+N+PE 380V |
| Rated current | 18A |
| Gross power | 8KW |
| Weight | 1800KG |
| Dimension | (L)2150×(W)1300×(H)1500mm |
