| 1 | Max web width | 370mm | 15 | Mercury lamp UV (Digital stamping) | 1 set |
| 2 | Range of foil width | 20~330mm | 16 | Web cean device | 1 set |
| 3 | Max inkjet speed | 50m/min (Depending on the substrate material） | 17 | Corona device | 1 set |
| 4 | Max foil stamping speed | 50m/min (Depending on the substrate material） | 18 | Flexo printing unit | 1 set |
| 5 | Unwind roll diameter | Ф500mm | 19 | UVdevice(forflexo) | 1 set |
| 6 | Rewind roll diameter | Ф500mm | 20 | Anilox roller | 300LPI*1pcs |
| 7 | Applicable material | Roll-fed material | 21 | Printing roller | 78T-190T)*1set |
| 8 | Web guide | Standard | 22 | Rotary die cutting unit | 1 set |
| 9 | Foil stamping method | Cold stamping (Optional for rotary hot stamping) | 23 | Magnetic cylinder | 152T*1set |
| 11 | Inkjet unit | 1 set | 25 | Air requirement | 0.4-0.6Mpa |
| 12 | Stamping unit | 1 set | 26 | Voltage | 3PH+N+PE 380V |
| 13 | Cooling mode | Water-cooling | 27 | Rated current | 100A |
| 14 | LED UV(Precuring) | 1 set | 28 | Dimension(L*W*H) | 6800mm*3000mm*2100mm |
| 29 | Tooling | 1 set |
